ProWarm™ Water Underfloor Heating Systems are the perfect choice for both homeowners and tradespeople seeking a Premium Branded water underfloor heating kit.

Our High Output - Water Underfloor Heating Single room kits are specifically designed for areas with high heat loss, such as conservatories, where you wish to combine the underfloor heating with a standard radiator system. Each kit is tailored to cover a specific area in square meters when the pipe is spaced at 200mm apart, providing an output of 125w per square meter. If you require a lower output, we also offer standard output kits for your convenience.

Please Note: ProWarm™ Water Underfloor Heating kits are equipped with advanced water temperature control, a feature to be cautious of when considering other systems. Our commitment to quality is evident in our choice to use only high-quality European Standard Pex-Al-HDPE pipe. The inclusion of an aluminium layer acts as an oxygen barrier, effectively preventing oxygen diffusion through the polymer matrix, and thereby eliminating corrosion risks for the metal components in the system.

ProWarm™ Water Underfloor Heating Kit Components:

Below are examples of the products included in your ProWarm™ Water Underfloor Heating Kit. For a comprehensive list of what you'll find in the box, please refer to our handy Kit Content Comparison Table below.

Grundfos Temperature Unit: A rated UPM3 Grundfos Single Circuit Constant Supply Temperature Unit.
Grundfos Mixing Unit: A rated UPM3 Grundfos Manifold Pump/Mixing Valve Unit.
2, 3, or 4 Port Manifold: Stainless steel manifold with adjustable flow meter, factory assembled on fixing bracket.
Manual Thermostat: Customize your kit by upgrading your thermostat to a digital, programmable, wireless, or touchscreen one for a small additional fee.
ProWarm™ European Standard PERT-AL-PERT Pipe: 16mm (outside) diameter PERT-AL-PERT pipe.
Tools: Pipe Re Rounding Tool, Pipe Staples, and Pipe Cutters for easy installation.
Edging Insulation: Edge Insulation is included to minimize unwanted heat loss and allow for expansion, placed around the edge of the room.

Compare Kits

This table shows exactly what you'll get in the box based on your chosen kit size.

Kit Size (m2)	10	12	14	16	18	20	22	24	30	40	50	60	70	80
Single Circuit Pump	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	X	X	X	X	X	X
Manifold Pump + Mixer	X	X	X	X	X	X	X	X	Yes	Yes	Yes	Yes	Yes	Yes
Manual Thermostat	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Manifold Ports	X	X	X	X	X	X	X	X	2	2	3	3	4	4
Pipe Length (m)	50	60	70	80	90	100	110	120	150	200	250	300	350	400
Edging Insulation	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Pipe re-rounding tool	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Pipe staples	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Pipe cutters	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Nuts and olives	X	X	X	X	X	X	X	X	Yes	Yes	Yes	Yes	Yes	Yes
Valves	X	X	X	X	X	X	X	X	Yes	Yes	Yes	Yes	Yes	Yes

Kit Size (m2)	10	12	14	16	18	20	22
Temperature Unit	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Manifold Pump + Mixer	X	X	X	X	X	X	X
Manual Thermostat	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Manifold Ports	X	X	X	X	X	X	X
Pipe Length (m)	50	60	70	80	90	100	110
Edging Insulation	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Pipe re-rounding tool	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Pipe staples	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Pipe cutters	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Nuts and olives	X	X	X	X	X	X	X
Valves	X	X	X	X	X	X	X

Kit Size (m2)	24	30	40	50	60	70	80
Temperature Unit	Yes	X	X	X	X	X	X
Manifold Pump + Mixer	X	Yes	Yes	Yes	Yes	Yes	Yes
Manual Thermostat	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Manifold Ports	X	2	2	3	3	4	4
Pipe Length (m)	120	150	200	250	300	350	400
Edging Insulation	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Pipe re-rounding tool	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Pipe staples	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Pipe cutters	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Nuts and olives	X	Yes	Yes	Yes	Yes	Yes	Yes
Valves	X	Yes	Yes	Yes	Yes	Yes	Yes

Specifications

Features	Values	Testing Methods
Material	Crosslinked polyethylene PE-Xb internal layer, internal bonding layer, intermediate aluminium layer, external bonding layer, high density polyethylene HDPE external layer.	-
Colour	RAL white 9003	-
Dimensions	14÷32 mm	-
Application	Hot and cold potable water distribution, convector and radiator heating systems, radiant heating and air cooling systems, compressed air distribution systems, industrial installations.	-
Fittings	Pexal Brass, Bravopress and Pexal Twist	-
Minimum operating Temperature⁽¹⁾	-60°C	-
Maximum temperature	+95°C/+100°C	EN ISO 21003-1
Maximum Pressure	+10 bar	EN ISO 21003-1
Density at 23°C	> 0.950 g/cm³ (crosslinked polyethylene)	-
Softening temperature	135°C	-
Thermal expansion coefficient	0.026 mm/m.K	-
Thermal conductivity	0.42÷0.52 W/m.K	-
Internal roughness	0.007 mm	-
Oxygen permeability	0 mg/l	-
UV Resistance	Yes, if protected with UV-resistant paint	-
Halogen levels	Halogen-free	-

(1) At any rate above the freezing temperature of the transported fluid.
